Features
■Semi-high-speed operation with double-sided tablet discharge.
■Maximum main compression force up to100 kN and maximum pre-compression force up to 30kN,exceeding the performance of conventional medium-and low-speed rotary tablet presses.
■Equipped with start/stop rejection and hopper powder level alarm functions.
■Features a cantilever-type operation display structure combined with a 10-inch color HMI from Siemens, providing real-time display of tablet thickness,fill depth,and compression force data.
■Utilizes an advanced volumetric thin-oil lubrication system to ensure accurate and reliable oil supply to all lubrication points.
■Handwheel-free operation,with main compression thickness and filling volume adjusted directly through the touchscreen interface.
■Optional anti-sticking punch equipment available.
■Optional bi- tablet compression device available.
